Our Manual Knife Gate Valve is a reliable and efficient solution for controlling flow in various industrial applications. This valve is designed with a handwheel operated mechanism, allowing for easy and precise operation.
Constructed with high-quality materials, this valve is built to withstand harsh conditions and provide long-lasting performance. The knife gate design ensures a tight seal and minimal leakage, making it ideal for handling thick fluids, slurries, and solids.
The handwheel operation allows for quick and simple adjustments, giving operators full control over flow rates. This valve is suitable for use in industries such as mining, wastewater treatment, pulp and paper, and more.
Trust in our Manual Knife Gate Valve for dependable flow control in your industrial processes.
| Model | TBZ73X | |||
| Working Pressure | DN50-DN100 16bar | DN125-DN200 10bar | DN250-DN400 7bar | DN450-DN600 5bar |
| DN650-DN750 4bar | DN800-DN900 3bar | DN1000 2bar | DN1100-DN1400 1bar | |
| Design Standard | MSS SP-81 | |||
| Flange Standard | DIN PN10 | DIN PN10 | 150LB | JIS 10K |
| TABLE E/D | ||||
| Face To Face | MSS SP-81 | |||
| Testing Standard | API-598 | |||
| Operation | Manual | |||
| Main Material | F55 | F53 | 2205 | CF3M |
| CF8M | CF8 | WCB | GGG40 | |
| Disc Material | F55 | F53 | 2205 | SS310 |
| SS316L | SS316 | SS304 | / | |
| Sealing Material | NBR | EPDM | PTFE | FKM |
| Graphite | Metal | / | / | |
| Packing | Aramid Fiber | High-Water Based Fiber | Rubber | PTFE |
| Graphite | ||||
| Applicable Medium | Pulp | Cement Slurry | Gold Ore Powder | Coal Slurry |
| Chemical Treatment Of Sewage | Sedimentation Tanks | Asphalt | Acid | |
| Waiting For Liquid Medium | ||||
